Arduino® MKR WiFi 1010

The Arduino MKR WiFi 1010 is the easiest point of entry to basic IoT and pico-network application design. Whether you are looking at building a sensor network connected to your office or home router, orif you want to create a Bluetooth® Low Energy device sending data to a cellphone, the MKR WiFi 1010 is your one-stop-solution for many of the basic IoT application scenarios.

The board's main processor is a low power Arm® Cortex®-M0 32-bit SAMD21, like in the other boards within the Arduino MKR family. The WiFi and Bluetooth® connectivity is performed with a module from u-blox, the NINA-W10, a low power chipset operating in the 2.4GHz range. On top of those, secure communication is ensured through the Microchip® ECC508 crypto chip. Besides that, you can find a battery charger, and a directional RGB LED on-board.

Technical specifications :

Microcontroller: SAMD21 Cortex®-M0+ 32bit low power ARM® MCU (datasheet)

Radio module: u-blox NINA-W102 (datasheet)

Board Power Supply (USB/VIN): 5V

Secure Element: ATECC508 (datasheet)

Supported Battery: Li-Po Single Cell, 3.7V, 1024mAh Minimum

Circuit Operating Voltage: 3.3V

Digital I/O Pins: 8

PWM Pins: 13 (0 .. 8, 10, 12, 18 / A3, 19 / A4)

UART: 1

SPI: 1

12C: 1

Analog Input Pins: 7 (ADC 8/10/12 bit)

Analog Output Pins: 1 (DAC 10 bit)

External Interrupts: 10 (0, 1, 4, 5, 6, 7, 8,9, 16 / A1, 17 / A2)

DC Current per I/O Pin: 7 mA

CPU Flash Memory: 256 KB (internal)

SRAM

SRAM: 32 KB

EEPROM: no

Clock Speed: 32.768 kHz (RTC), 48 MHz

LED_BUILTIN: 6

USB: Full-Speed USB Device and embedded Host

Length: 61.5 mm

Width: 25 mm

Weight: 32 g
